The Opengear ACM7000-L Resilience Gateway delivers enterprise-grade remote monitoring and infrastructure management with 4G LTE-A Pro cellular capabilities. This TAA-compliant solution ensures continuous uptime for branch offices, retail locations, and remote sites through Smart OOB™ technology and Failover to Cellular™ protection.
Advanced Network Resilience Features
4G LTE-A Pro cellular connectivity with dual SIM capability for reliable backup
Smart OOB™ technology for proactive issue identification and remediation
Failover to Cellular™ with IP Passthrough for seamless network continuity
Integrated RESTful API engine for automated management
4 serial ports with Cisco straight pinout and 4 USB 2.0 console ports
Enterprise-Grade Security and Compliance
PCI DSS 3.2 and FIPS140-2 compliance
Stateful firewall with SSL and SSH encryption
OpenVPN & IPsec support
4GB local storage for secure audit trails
Environmental monitoring with SMS, SNMP, and email alerts
Cellular Speeds: Up to 600 Mbps download/150 Mbps upload (CAT-12)
Package Contents
ACM7000-L Resilience Gateway
Rack Mount Kit with Ear and Screw (590003)
Digital I/O Black Terminal Block (319115)
DB9F-RJ45 Straight Adapter (319015)
4 Rubber Feet (370003)
12VDC Universal Power Supply (450031)
2 4G Cellular Blade Antennas
ACM7000-L Antenna Extension Kit (590051)
Quick Start Guide
L'ACM7000-L Resilience Gateway garantisce un'elevata disponibilità presso sedi distaccate, negozi al dettaglio, chioschi e altri siti remoti. L'accesso cellulare fornisce un gateway sempre attivo ai dispositivi della rete esterna, anche quando la rete principale è giù.
Identificare e risolvere i problemi al margine della rete prima che diventino guasti con Smart OOB™. Massimizzare la resilienza della WAN con Failover to Cellular™ verso reti 4G LTE e capacità multicarrier integrate.
4-8 porte seriali, gestione out-of-band dei dispositivi di rete e server
4 porte console USB 2.0, gestione out-of-band dei dispositivi di rete e server
Smart OOB va oltre la tradizionale gestione out-of-band
Failover to Cellular™ e IP Passthrough per accesso out-of-band e connettività di failover della rete tramite cellulare.
Motore API RESTful integrato sui dispositivi con firmware 4.0 o superiore
Gestire tutti i router di rete, firewall, UPS, PDU con console seriali, USB ed Ethernet
Centralizzare la gestione di tutti i siti remoti e data center dell'azienda con Lighthouse 5
Rilevare e ripristinare automaticamente i guasti e riparare i difetti dell'attrezzatura
Protocollo di scoperta del livello di collegamento (LLDP) per scoprire, identificare e verificare i dispositivi collegati alla rete locale.
Registrazione dei log su memoria locale integrata da 4GB per risoluzione dei problemi e conformità
Sicurezza avanzata, compatibilità PCI DSS 3.2, FIPS140-2, SSL e SSH, firewall stateful, OpenVPN e IPsec
Sensore interno integrato di temperatura
Notifica di allarme del sensore ambientale e fisico via SMS, SNMP o email
.
Return Policy
Time to Return
Standard Return Policy
We offer a hassle-free 30-day returns policy for domestic (US) orders, excluding non-refundable items. Refund or Replacement within 30 days of the delivery date. All products that fall under the Standard Return
Policy
qualify for our 30-Day Hassle-Free Returns. Please see the section above for more details.
Replacement Only Return Policy
Replacement within 30 days of the delivery date.
Manufacturer Only Return Policy
Covered by the manufacturer's warranty.
Please refer to the terms and conditions for the manufacturer's warranty or contact the manufacturer.
Holiday Extended Return Policies
Extended Holiday Return Policy.
Qualifying purchases of products displaying the " Extended Holiday
Return Policy ",
from November 1st, 2023 to December 25, 2023, are eligible for a Refund or Replacement until January 31,
2024.
Extended Holiday Replacement-Only Return Policy
Qualifying purchases of products displaying the " Extended Holiday
Replacement-Only Return Policy ",
from November 1st, 2023 to December 25, 2023, are eligible for a Replacement until January 31, 2024.
Advanced 4G LTE Connectivity with Dual Antenna Design
The ACM7004-5-L features dual high-performance cellular antennas that maximize signal strength and reliability for mission-critical remote management. The strategically positioned blade antennas ensure optimal reception across multiple cellular bands, while supporting speeds up to 600 Mbps download and 150 Mbps upload through LTE-A Pro technology.
Technical Specifications
Dual SMA antenna connectors with diversity support
LTE-A Pro compatible with global band support
Supports speeds up to 600/150 Mbps
Applications
Remote site connectivity in signal-challenging environments
Backup cellular connection for enterprise branch offices
Primary connectivity for temporary deployment locations
Intelligent Dual Network Interface Design
The front panel showcases the device's dual-network capability with dedicated NET1 and NET2 ports, enabling seamless failover and load balancing. The clean interface design incorporates status LEDs for quick visual monitoring of network health and system status, while the integrated SIM card slots provide flexible carrier options.
Technical Specifications
Dual 10/100/1000 Ethernet ports for primary and failover
Built-in status LED indicators for system monitoring
Dual SIM card slots for carrier redundancy
Applications
Network failover implementation for business continuity
Multi-carrier cellular backup configuration
Remote infrastructure monitoring and management
Comprehensive Connectivity Interface Array
The rear panel delivers extensive connectivity options with four serial ports, USB interfaces, and cellular antenna connections. This comprehensive I/O layout supports diverse remote management scenarios while maintaining a compact form factor. The DC power input ensures reliable operation across various deployment environments.
Technical Specifications
4 RJ45 serial ports with RS-232 support
4 USB 2.0 ports for console management
9-30V DC power input range
Applications
Serial console management for network equipment
USB device connectivity for remote access
Integrated infrastructure monitoring setup
FAQ
The Opengear ACM7000-L Resilience Gateway is an infrastructure management equipment designed to ensure network uptime at remote sites like branch offices, retail stores, and kiosks. Its primary purpose is to provide always-on gateway access to off-site network devices through cellular connectivity, even during primary network failures. It features Smart OOB™ technology for early issue detection and Failover to Cellular™ with 4G LTE-A Pro capabilities for maximum WAN resilience.
The ACM7004-5-L offers multiple connectivity options including: 4 RJ45 RS-232 serial ports (50 to 230,400bps, Cisco pinout), 2 RJ45 10/100/1000 Ethernet ports for primary and failover connections, 4 USB 2.0 console ports, 2 TTL level Digital I/O ports for external sensors, and 2 High Voltage Digital Outputs. It also features dual SIM slots for cellular connectivity with support for LTE-A Pro, offering download speeds up to 600 Mbps and upload speeds up to 150 Mbps.
The ACM7000-L has compact dimensions measuring 1.4" in height, 5.1" in width, and 4.7" in depth, weighing approximately 1.32 lb. It offers versatile mounting options including rail-mountable, desktop, and rack mount installations. The device comes with a rack mount kit (ear and screw) and rubber feet for desktop placement, making it adaptable to various deployment scenarios.
The ACM7000-L includes comprehensive security features such as IPsec & OpenVPN, SSL tunnels, SSH V2, TACACS+, Kerberos, RADIUS and LDAP authentication, and a stateful firewall. It's compliant with PCI DSS 3.2, features FIPS140-2 validated module (Certificate #2473), and supports NERC CIP standards. The device also includes security certifications from CE, UL 1950, TUV, and C-Tick, ensuring robust security for enterprise deployments.
The ACM7000-L is designed to operate in diverse environmental conditions with an ambient operating temperature range of -25°C to 60°C (-13°F to 140°F) and humidity tolerance of 5% to 90%. The non-operating storage temperature range is -40°C to 75°C (-40°F to 167°F). The device features built-in environmental monitoring capabilities with an embedded internal temperature sensor and can send alarm notifications via SMS, SNMP, or email.
The ACM7000-L features advanced cellular capabilities with a Sierra Wireless EM7565 global cellular module supporting LTE-A Pro (LTE-LAA) and HSPA+. It includes dual push-click 2FF SIM slots and supports multiple frequency bands including 4G LTE bands (B1-B66) and 3G HSPA+ bands. The device achieves peak transfer rates of 600 Mbps download and 150 Mbps upload (CAT-12), and comes with 2 4G cellular blade antennas for optimal connectivity.
The ACM7000-L offers comprehensive management features including HTTPS & SSH console access, Nagios NSCA & NRPE, SNMP monitoring, TFTP & FTP server capabilities, and an integrated RESTful API engine. It supports centralized management through Lighthouse 5, features Link Layer Discovery Protocol (LLDP) for device detection, and includes 4GB local storage for audit trails. The system can automatically detect and recover from outages and equipment faults.
The ACM7000-L package includes the Resilience Gateway unit, rack mount kit with ear and screw (Part# 590003), digital I/O black terminal block, DB9F-RJ45 straight adapter, 4 rubber feet, 12VDC universal power supply, 2 4G cellular blade antennas, antenna extension kit (for -L variants), and a quick start guide. The device comes with a 4-year warranty and is TAA compliant, manufactured in the United States.
